GLV18-8-200/25/102/115 | M18 Diffuse Sensor, 200mm, NPN, Cable
GLV18-8-200/25/102/115 photoelectric sensor. M18 threaded barrel, diffuse mode, 50-200mm range, NPN output, 10-30V DC, 2m fixed cable, IP67.
Product Overview
The GLV18-8-200/25/102/115 is an M18 cylindrical diffuse mode photoelectric sensor from the Efficient Line series. It features a plastic housing and a front optical face for detecting objects without physical contact. Key attributes include an adjustable sensing range of 50-200 mm, a modulated visible red light source (640 nm) for immunity to ambient light, and a 2-meter fixed cable for direct wiring. This sensor is designed for standard automation tasks requiring reliable object detection in limited spaces.
Technical Specifications (Electrical & Optical)
| Parameter | Specification |
| Manufacturer Part No. | GLV18-8-200/25/102/115 |
| Operating Voltage | 10 ... 30 V DC |
| Output Type | 1 NPN, Open Collector, Short-circuit Protected |
| Switching Current | Max. 100 mA |
| Switching Frequency | 500 Hz |
| Light Source | Modulated Visible Red LED (640 nm) |
| Detection Range | 50 ... 200 mm (Adjustable via Potentiometer) |
| Max. Detection Range | 0 ... 200 mm |
| Reference Target | 100 mm x 100 mm Kodak White |
| Ambient Light Immunity | ≤ 30000 Lux |
Technical Specifications (Mechanical & Environmental)
| Parameter | Specification |
| Housing | Plastic (PC), M18 x 1 Threaded Barrel |
| Optical Face | Front |
| Connection | 2 m Fixed Cable (PVC) |
| Cable Configuration | 3-wire (Brown: +Ub, Blue: 0V, Black: Output) |
| Degree of Protection | IP67 |
| Operating Temperature | -25 °C ... +60 °C |
| Housing Length | 39.8 mm |
| Weight | Approx. 75 g |
| Standard | EN 60947-5-2 |
Key Features
-
Adjustable Sensitivity: Built-in potentiometer allows fine-tuning of the sensing range (50-200 mm) to adapt to different object colors and surfaces.
-
High Visibility: 360° LED indicator (green for power, yellow for signal) for easy status monitoring during commissioning and operation.
-
Fixed Cable Output: Pre-wired with a 2-meter cable (NPN output), eliminating the need for separate connectors and simplifying installation.
Applications
-
Object detection on conveyor belts and material handling systems
-
Presence sensing in packaging machinery and assembly automation
-
Level detection in bins and hoppers (non-contact)
